Sonicware LIVEN Texture Lab - Synchronization Connection Examples; External Device as Clock Master Configuration

81 pages

Save Page as PDF

To Next Page

To Previous Page

Clock synchronization with

external devices — Connection examples

External device as clock master

SYNC OUT

Volca series

SRC set to

SYNC

oror

SRC set to

MIDI

PO seriesMIDI device

MIDI OUT

Make only one device the clock master

OUTPUT

SRC set to

LN.IN
