Sonos CONNECT:AMP Product Guide

Sonos Controller for Mac or PC
B-11
Sonos Controller 100
* Specifications subject to change without notice.
Feature Description
Display and User Interface
Screen Type
Transflective LCD screen, with adjustable backlighting
Screen Resolution
3.5” (diagonal) color LCD, 240 x 320 (QVGA)
Browse Control
Touch-sensitive scroll wheel with center-mounted selector button
Function Buttons
9 Backlit buttons, 3 soft-selector buttons below screen
Indicators
Wireless signal strength and battery charge indicator (on-screen), battery status indicator
LEDs.
Power/Connections
Battery Type
Battery Charging Time
Rechargeable Li-ION Polymer battery, factory replaceable
2 hours to fully charge
DC Charger
Input 100-240 VAC, 50/60 HZ, Output 6 VDC, 3.8 A
Auxiliary Power Connection
Bottom-mounted charger contacts
Wireless Connectivity
SonosNet a secure AES encrypted peer-to-peer wireless mesh network
General
Dimensions
6.5”x 3.8” x 0.95” (165mm x 97mm x 24.5mm)
Weight
12.5 oz. (360 g)
Finish
Metal cladding on light gray enclosure, splash-resistant

Sonos CONNECT:AMP Specifications

General

Audio decoders	Dolby Digital
Amplifier class	D
Frequency range	22 - 20000 Hz
RMS rated power	110 W
Built-in crossover	Yes
Crossover frequency	80 Hz
Audio output channels	2.1 channels
Peak power per channel	55 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.02 %
Purpose	Home
Material	Aluminum
Product color	White
Connectivity technology	Wired
Audio (L/R) out	2
Headphone outputs	1
Headphone connectivity	3.5 mm
Speakers connectivity type	Banana connector/Binding posts
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	207 mm
Width	185 mm
Height	89 mm
Weight	2300 g
