Product Guide
B-10
SONOS SUB
* Specifications subject to change without notice.
Feature Description
Audio
Amplifier
Two Class-D digital amplifiers
Speakers
Two force-cancelling speakers positioned face-to-face for deeper, richer sound and zero
cabinet buzz or rattle.
Dual Acoustic Ports
Tuned to enhance the SUB performance.
Frequency Response
Plays down to 25 Hz.
All Digital Sound
All filter settings, active equalization, and time alignment are done digitally through state-of-
the-art DSP (Digital Signal Processing) circuitry for zero-loss audio quality and energy.
Automatic Equalization
The system automatically adjusts audio settings across all connected components.
Networking
Ethernet Port
One Ethernet port that can connect the SUB to a wired home network.
Wireless Connectivity
SonosNet 2.0, a secure AES encrypted, peer-to-peer wireless mesh network
SonosNet Extender
Functions to extend and enhance the power of SonosNet 2.0
General
Side Panel Button (Join Button)
Join household
Side Panel LEDs
Indicate SUB status
Power Supply
AC 100-240V, 50-60 Hz
Dimensions (H x D x W)
15.8 x 6.2 x 15in. (402 x 158 x 380mm)
Weight
36.3 lbs (16kgs)
Operating Temperature
32°F to 104°F (0°C to 40°C)
Storage Temperature
4°F to 158°F (-20°C to 70°C)
Multiple Orientations
Stand upright or lay flat for flexible placement.
Rubber and Felt Feet
Built-in rubber feet; optional felt feet included.
Supported Devices
SUB works with all Sonos amplified components: CONNECT:AMP/ZP120/ZP100;
PLAY:5/ ZonePlayer S:5; PLAY:3.
Does not work with the non-amplified SONOS CONNECT/ ZP90/ZP80.
