Sonos CONNECT:AMP Product Guide

Sonos Controller for Mac or PC
2-29
SONOS SUB
Join button Press the Join button to associate the SUB with your Sonos Wireless HiFi System.
Acoustic slot The top of the acoustic slot doubles as a handle so you can lift it.
SUB placement: Make sure at least one side of the slot is free from obstruction. If you
place it vertically against a wall, do not block the front opening. If you place the SUB
horizontally on the floor, don’t put anything on top of it.
SUB status indicator LED indicates the SUB status.
• For a complete list of status indicators, please go to http://faq.sonos.com/led.
Ethernet port Use an Ethernet cable to connect the SUB to your home network.
AC power (mains) input Use the supplied power cord to connect to a power outlet. Be sure to use the proper
power adapter for your country. Push the power cord firmly into the SUB until it is flush
with the surface.
Join button
Ethernet port AC Power (Mains)
Acoustic slot
Status indicator

Sonos CONNECT:AMP Specifications

General

Audio decoders	Dolby Digital
Amplifier class	D
Frequency range	22 - 20000 Hz
RMS rated power	110 W
Built-in crossover	Yes
Crossover frequency	80 Hz
Audio output channels	2.1 channels
Peak power per channel	55 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.02 %
Purpose	Home
Material	Aluminum
Product color	White
Connectivity technology	Wired
Audio (L/R) out	2
Headphone outputs	1
Headphone connectivity	3.5 mm
Speakers connectivity type	Banana connector/Binding posts
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	207 mm
Width	185 mm
Height	89 mm
Weight	2300 g
