Sonos CONNECT:AMP Product Guide

Sonos Controller for Mac or PC
B-7
* Specifications subject to change without notice.
Motion Sensor
Detects when the Controller is picked-up and automatically wakes it from battery-saving sleep
mode
Power/Connections
Battery
High density rechargeable 1850mAh Li-ION Polymer battery; user-replaceable through battery
door on back of the Controller.
DC Charger
Input 100-240 VAC, 50/60 HZ, Output 5 VDC, 2 A
Battery Charging Time
2 hours to fully charge
Battery Life
2-5 days of use between charging (depending on usage pattern and sleep timer settings)
Wireless Connectivity
SonosNet a secure AES encrypted peer-to-peer wireless mesh network
General
Dimensions
Controller: 2.9 x 4.5 x 0.7 in. (72.9 x 115.5 x 17 mm)
Cradle: 3.2 x 3.0 x 2.4 in. (80.8 x 75.1 x 60.3 mm)
Weight
Controller: 6.7 oz. (190 g)
Cradle: 6.0 oz. (170g)
Finish
Rugged glass screen; anodized precision machined extrusion aluminum case with soft durable
rubber backing.

Sonos CONNECT:AMP Specifications

General

Audio decoders	Dolby Digital
Amplifier class	D
Frequency range	22 - 20000 Hz
RMS rated power	110 W
Built-in crossover	Yes
Crossover frequency	80 Hz
Audio output channels	2.1 channels
Peak power per channel	55 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.02 %
Purpose	Home
Material	Aluminum
Product color	White
Connectivity technology	Wired
Audio (L/R) out	2
Headphone outputs	1
Headphone connectivity	3.5 mm
Speakers connectivity type	Banana connector/Binding posts
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	207 mm
Width	185 mm
Height	89 mm
Weight	2300 g
