Sony DCR-PC1 - BIST Check; Playback System Check; Preparation for Playback; IC1900 (TRX) bist (PB) Check

5-40
3-5-2. BIST Check
1. Playback System Check
1-1. Preparation for Playback
1) Set the POWER switch to the VTR (or PLAYER) position.
2) Connect the adjustment remote commander and set the HOLD
switch to the ON (SERVICE) position.
3) Playback the BIST check tape. (XH5-6 (NTSC), XH5-6P (PAL))
Note: Perform all of the following checks in the playback mode.
1-2. IC1900 (TRX) BIST (PB) Check
1) Select page: 3, address: 12, set data: 04, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 3, address: 12, set data: 00, and press the PAUSE
button of the adjustment remote commander.
3) Select page: 3, address: 13, set data: 02, and press the PAUSE
button of the adjustment remote commander.
4) When the playback system from IC1900 (TRX) to IC1601
(TDF) is normal, the display data (combination data) of page:
3, addresses: 16 and 17 agree with any combination as shown
below.
NTSC model
PAL model
1-3. IC1601 (TFD), BIST (PB) Check
1) Select page: 3, address: 40, set data: 0F, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 3, address: 40, set data: 00, and press the PAUSE
button of the adjustment remote commander.
3) When the playback system from IC1601 (TFD) to IC1600
(SFD) is normal, the display data (combination data) of page:
3, addresses: 41 and 42 agrees with any combination as shown
below.
NTSC model PAL model
Address
16
17
63
84
C5
55
75
07
D3
D6
59
01
FF
D0
Data
Address
41
42
Data
26
A1
Address
14
15
Data
41
81
1-4. IC1600 (SFD) BIST (PB) Check
1) Select page: 0, address: 01, and set data: 01.
2) Select page: C, address: AC, set data: 21, and press the PAUSE
button of the adjustment remote commander.
3) Select page: C, address: AD, set data: 03, and press the PAUSE
button of the adjustment remote commander.
Note: Perform the following data setting while playing back the BIST
check tape.
4) Select page: 3, address: 11, set data: 04, and press the PAUSE
button of the adjustment remote commander.
5) Select page: 3, address: 12, set data: 08, and press the PAUSE
button of the adjustment remote commander.
6) Select page: 3, address: 12, set data: 00, and press the PAUSE
button of the adjustment remote commander.
7) Select page: 3, address: 13, set data: 03, and press the PAUSE
button of the adjustment remote commander.
8) When the playback system from IC1600 (SFD) to IC2003
(ADC&DAC) is normal, the display data (combination data)
of page: 3, addresses: 14 and 15 agrees with any combination
as shown below.
NTSC model PAL model
9) When the playback system from IC1600 (SFD) to IC1602 (LIP)
is normal, the display data (combination data) of page: 3,
addresses: 16 and 17 agrees with any combination as shown
below.
NTSC model PAL model
10) When the playback system from IC1600 (SFD) to IC1601
(TDF) is normal, the display data (combination data) of page:
3, addresses: 18 and 19 agrees with any combination as shown
below.
NTSC model PAL model
11) When the playback system from IC1600 (SFD) to IC1501
(VFD) is normal, the display data (combination data) of page:
3, addresses: 1A and 1B agrees with any combination as shown
below.
NTSC model PAL model
12) Select page: C, address: AC, set data: 20, and press the PAUSE
button of the adjustment remote commander.
13) Select page: C, address: AD, set data: 02, and press the PAUSE
button of the adjustment remote commander.
14) Select page: 0, address: 01, and set data: 00.
1E
B4
F0
31
Data Address
16
17
72
F8
16
5C
Data Address
18
19
Address
1A
1B
Data
12
43
Address
16
17
86
35
33
AA
90
B6
Data
Address
41
42
Data
69
73
Address
14
15
Data
2D
7C
Address
16
17
Data
1C
A6
Address
18
19
Data
A7
CC
Address
1A
1B
Data
90
CE
