6-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
CD-203
A-7073-672-A CD-203 BOARD, COMPLETE
**********************
(Ref. No.:4,000 Series)
(IC450 is not included to mountred board)
< CAPACITOR >
C450 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C451 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C452 1-125-841-91 TANTAL. CHIP 22uF 20% 4V
C453 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C454 1-125-841-91 TANTAL. CHIP 22uF 20% 4V
C455 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C456 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C457 1-125-841-91 TANTAL. CHIP 22uF 20% 4V
C458 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C459 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
* C460 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C462 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C465 1-107-820-11 CERAMIC CHIP 0.1uF 16V
* C467 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C468 1-113-990-11 TANTAL. CHIP 15uF 20% 16V
* C469 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C471 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C472 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C473 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C474 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C475 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C476 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C477 1-125-841-91 TANTAL. CHIP 22uF 20% 4V
< CONNECTOR >
CN450 1-750-360-21 CONNECTOR, FFC/FPC (ZIF) 24P
CN451 1-778-592-21 CONNECTOR, BOARD TO BOARD 50P
< IC >
IC450 A-7030-881-A CCD BLOCK ASSY (CCD IMAGER) (PC1)
IC450 A-7030-885-A CCD BLOCK ASSY (CCD IMAGER) (PC1E)
IC451 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L450 1-414-757-11 INDUCTOR 100uH
L451 1-414-771-91 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q450 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R451 1-218-990-11 SHORT 0
R452 1-218-969-11 RES,CHIP 22K 5% 1/16W
R453 1-218-990-11 SHORT 0
R454 1-218-959-11 RES,CHIP 3.3K 5% 1/16W
R455 1-218-969-11 RES,CHIP 22K 5% 1/16W
R456 1-218-969-11 RES,CHIP 22K 5% 1/16W
R457 1-218-969-11 RES,CHIP 22K 5% 1/16W
R458 1-218-965-11 RES,CHIP 10K 5% 1/16W
R459 1-218-965-11 RES,CHIP 10K 5% 1/16W
R460 1-218-989-11 RES,CHIP 1M 5% 1/16W
R461 1-218-967-11 RES,CHIP 15K 5% 1/16W
R462 1-218-989-11 RES,CHIP 1M 5% 1/16W
R463 1-218-941-11 RES,CHIP 100 5% 1/16W
R464 1-218-990-11 SHORT 0
R465 1-218-990-11 SHORT 0
R466 1-218-990-11 SHORT 0
R467 1-218-990-11 SHORT 0
< SENSOR >
SE450 1-803-042-31 SENSOR, ANGULAR VELOCITY (YAW)
SE451 1-801-731-81 SENSOR, ANGULAR VELOCITY (PITCH)
************************************************************
A-7073-669-A DD-111 BOARD, COMPLETE
**********************
(Ref. No.:10,000 Series)
< CAPACITOR >
C3201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C3202 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
* C3204 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C3206 1-125-840-91 TANTALUM 10uF 20% 6.3V
C3207 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3208 1-125-840-91 TANTALUM 10uF 20% 6.3V
C3209 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C3210 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C3211 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C3212 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3213 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C3215 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C3216 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C3217 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C3218 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
DD-111
