6-11
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C3219 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C3220 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C3221 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C3222 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3223 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3224 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3225 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3226 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3227 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3228 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C3229 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3230 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C3232 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3233 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3234 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3235 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C3238 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3239 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3240 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3241 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3242 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3243 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3245 1-109-994-11 CERAMIC CHIP 2.2uF 10% 10V
C3246 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C3247 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3251 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3252 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3253 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3256 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3257 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3258 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3267 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3268 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3269 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3270 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3271 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3272 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C3273 1-113-987-11 TANTAL. CHIP 4.7uF 20% 25V
C3274 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C3275 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3276 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C3277 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
* C3284 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
< CONNECTOR >
CN3200 1-778-595-21 CONNECTOR, BOARD TO BOARD 20P
CN3201 1-778-593-21 CONNECTOR, BOARD TO BOARD 60P
CN9900 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D3205 8-719-066-34 DIODE RB461F-T106
D3206 8-719-066-34 DIODE RB461F-T106
D3207 8-719-066-34 DIODE RB461F-T106
D3209 8-719-066-16 DIODE RB491D-T146
D3210 8-719-066-16 DIODE RB491D-T146
D3212 8-719-066-16 DIODE RB491D-T146
D3213 8-719-027-77 DIODE MA796-TX
D3215 8-719-066-16 DIODE RB491D-T146
D3221 8-719-056-48 DIODE 1SS388(TPL3)
D3222 8-719-066-34 DIODE RB461F-T106
D3223 8-719-056-61 DIODE MAZS082008SO
D3224 8-719-056-57 DIODE MAZS091008SO
D3225 8-719-056-57 DIODE MAZS091008SO
D3226 8-719-056-57 DIODE MAZS091008SO
D9901 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D9903 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D9905 8-719-056-61 DIODE MAZS082008SO
D9906 8-719-056-61 DIODE MAZS082008SO
< FUSE >
! F3202 1-533-981-11 FUSE, MICRO
! F3203 1-533-981-11 FUSE, MICRO
! F3204 1-533-981-11 FUSE, MICRO
! F3205 1-533-981-11 FUSE, MICRO
< IC >
IC3200 8-759-491-09 IC MB4488PFV-G-BND-ER
< JACK >
J9900 1-691-737-11 JACK (SMALL TYPE) (MIC (PLUG IN POWER))
J9901 1-778-518-11 CONNECTOR, EXTERNAL (S VIDEO)
J9902 1-778-040-11 JACK, SMALL TYPE (AUDIO/VIDEO)
J9903 1-565-276-31 JACK, ULTRA SMALL 1P (LANK)
< COIL >
L3204 1-416-346-11 INDUCTOR 33uH
L3205 1-416-346-11 INDUCTOR 33uH
L3206 1-416-705-21 INDUCTOR 22uH
L3207 1-416-345-11 INDUCTOR 22uH
L3208 1-416-727-21 INDUCTOR 22uH
L3209 1-416-345-11 INDUCTOR 22uH
L3210 1-414-770-91 INDUCTOR CHIP 4.7uH
L3212 1-414-396-21 INDUCTOR 4.7uH
L3213 1-414-770-91 INDUCTOR CHIP 4.7uH
L3214 1-414-770-91 INDUCTOR CHIP 4.7uH
L3215 1-414-770-91 INDUCTOR CHIP 4.7uH
L3216 1-414-770-91 INDUCTOR CHIP 4.7uH
L3217 1-414-770-91 INDUCTOR CHIP 4.7uH
L3218 1-414-396-21 INDUCTOR 4.7uH
L3219 1-416-668-11 INDUCTOR 10uH
L3220 1-416-668-11 INDUCTOR 10uH
L3221 1-416-668-11 INDUCTOR 10uH
L3222 1-416-668-11 INDUCTOR 10uH
L3223 1-414-396-21 INDUCTOR 4.7uH
L3226 1-414-770-91 INDUCTOR CHIP 4.7uH
L3227 1-414-770-91 INDUCTOR CHIP 4.7uH
L3228 1-414-770-91 INDUCTOR CHIP 4.7uH
< TRANSISTOR >
Q3206 8-729-822-05 TRANSISTOR 2SD1622-ST-TD
Q3207 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3208 8-729-043-60 TRANSISTOR CPH6102-TL
Q3209 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q3210 8-729-044-33 TRANSISTOR CPH6701-TL
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
DD-111
To Next Page
