1-2. INITIALIZATION OF F, E PAGE DATA
1. Initializing the F, E Page Data
Note: If the F, E page data has been initialized, the following adjustments
need to be performed again.
1) Modification of F, E Page Data
2) Camera System Adjustments
Adjusting page F
Adjusting Address 10 to FF
Adjusting page E
Adjusting Address 00 to 3D
Initializing Method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 6, address: 01, set data: 2D (NTSC) or data: 2F
(PAL), and press the PAUSE button of the adjustment remote
commander.
3) Select page: 6, address: 03, set data: 01, and press the PAUSE
button of the adjustment remote commander.
4) Select page: 6, address: 02, and check that the data is “01”.
5) Perform “Modification of F, E Page Data”.
2. Modification of F, E Page Data
If the F, E PAGE data has been initialized, change the data of the
“Fixed data-2” address shown in the following tables by manual
input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camcorder
may not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing After Modifying Data:
1) Select page :2, address:00, set data: 29, and press the PAUSE
button of the adjustment remote commander.
2) Select page :2, address:01, set data: 29, and press the PAUSE
button of the adjustment remote commander.
3) Perform “Camera System Adjustments”.
3. F Page Table
Note: Fixed data-1 : Initialized data ( Refer to “1. Initializing the F, E
Page Data”.)
Fixed data-2 : Modified data (Refer to “2. Modification of F, E Page
Data”).
Address
00 to 0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
NTSC
80
40
5E
90
3E
43
59
51
19
22
20
93
13
64
22
27
80
40
00
00
46
00
19
00
2A
00
80
7A
PAL
80
40
5E
B4
55
86
7B
51
19
22
20
93
13
64
22
24
80
40
00
00
46
00
19
00
2A
00
80
7A
Remark
Fixed data-1
(Initialized data)
36MHz origin osc adj.
Fixed data-1
Hall adj.
AWB & LV standard data input
Flange back adj.
Fixed data-1
(Initialized data)
Max gain adj.
Fixed data-1
Color reproduction adj.
Fixed data-1
Color reproduction adj.
Fixed data-1
(Initialized data)
Auto white balance adj.
Flange back adj.
AWB & LV standard data input
Initial value
