Sony DCR-PC1 - Flexible Boards Location

2-8E
2-11.FLEXIBLE BOARDS LOCATION
CONTROL SWITCH BLOC
K
(FK-4780)
CONTROL SWITCH BLOC
K
(ME-4780)
FP-586
(From LOADING MOTOR)
(From VIDEO HEAD)
(From DRUM MOTOR)
(From CAPSTAN MOTOR)
FP-585
(MODE)
