6-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
IC2006 8-759-541-70 IC RN5RG28AA-TL
IC2200 8-759-398-90 IC S-81236PG-P7-T1
IC2201 8-759-424-79 IC S-8423YFS-T2
IC2203 8-759-536-72 IC TL1596CPWR
IC2204 8-759-545-06 IC S579C15AGGB-SGX4780-TEB
IC2401 8-759-563-16 IC MB91191LGA-G-120-BND-ER
IC2404 8-759-445-94 IC AK6480AM-E2
IC3400 8-759-534-60 IC S-8328B55MC-EXJ-T2
IC3401 8-759-096-87 IC TC7WU04FU(TE12R)
IC3402 8-759-536-88 IC RN5RZ28BA-TL
IC5000 8-759-546-65 IC CXA8115AR-T4
IC5001 8-759-530-19 IC MB40D001PFV-G-BND-ER
IC5002 8-752-392-33 IC CXD2458AR-T4
< COIL >
L201 1-414-771-91 INDUCTOR CHIP 10uH
L202 1-414-771-91 INDUCTOR CHIP 10uH
L203 1-414-771-91 INDUCTOR CHIP 10uH
L204 1-414-771-91 INDUCTOR CHIP 10uH
L205 1-414-771-91 INDUCTOR CHIP 10uH
L206 1-414-771-91 INDUCTOR CHIP 10uH
L501 1-414-771-91 INDUCTOR CHIP 10uH
L502 1-414-771-91 INDUCTOR CHIP 10uH
L503 1-414-771-91 INDUCTOR CHIP 10uH
L504 1-414-771-91 INDUCTOR CHIP 10uH
L1400 1-414-771-91 INDUCTOR CHIP 10uH
L1404 1-414-771-91 INDUCTOR CHIP 10uH
L1500 1-414-771-91 INDUCTOR CHIP 10uH
L1501 1-414-771-91 INDUCTOR CHIP 10uH
L1601 1-414-245-11 INDUCTOR 1.5uH
L1602 1-414-771-91 INDUCTOR CHIP 10uH
L1603 1-414-771-91 INDUCTOR CHIP 10uH
L1604 1-414-771-91 INDUCTOR CHIP 10uH
L1605 1-414-771-91 INDUCTOR CHIP 10uH
L2001 1-414-771-91 INDUCTOR CHIP 10uH
L2002 1-414-771-91 INDUCTOR CHIP 10uH
L2003 1-414-757-11 INDUCTOR 100uH
L2004 1-414-771-91 INDUCTOR CHIP 10uH
L2005 1-414-771-91 INDUCTOR CHIP 10uH
L2201 1-414-771-91 INDUCTOR CHIP 10uH
L2400 1-216-295-91 SHORT 0
L2900 1-469-058-11 INDUCTOR CHIP 22uH
L3400 1-414-771-91 INDUCTOR CHIP 10uH
L3403 1-416-705-21 INDUCTOR 22uH
L3404 1-414-771-91 INDUCTOR CHIP 10uH
L5000 1-414-771-91 INDUCTOR CHIP 10uH
L5001 1-469-058-11 INDUCTOR CHIP 22uH
L5004 1-469-058-11 INDUCTOR CHIP 22uH
L5006 1-412-947-11 INDUCTOR 4.7uH
< IC LINK >
! PS2200 1-533-874-11 FUSE, MICRO
< TRANSISTOR >
Q201 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q202 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q203 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q204 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q205 8-729-429-00 TRANSISTOR UN9119J-(K8).SO
Q501 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q502 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q503 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q1500 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q1501 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q1502 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q1503 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q1504 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q2000 8-729-429-50 TRANSISTOR XP4312-TXE
Q2001 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q2002 8-729-427-72 TRANSISTOR XP4501-TXE
Q2003 8-729-427-72 TRANSISTOR XP4501-TXE
Q2006 8-729-023-85 TRANSISTOR 2SJ168(TE85L)
Q2007 8-729-429-50 TRANSISTOR XP4312-TXE
Q2008 8-729-023-85 TRANSISTOR 2SJ168(TE85L)
Q2009 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q2010 8-729-427-72 TRANSISTOR XP4501-TXE
Q2011 8-729-012-64 TRANSISTOR 2SB1396-S/T/U-TD
Q2012 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q2013 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q2014 8-729-429-50 TRANSISTOR XP4312-TXE
Q2015 8-729-023-85 TRANSISTOR 2SJ168(TE85L)
Q2016 8-729-023-85 TRANSISTOR 2SJ168(TE85L)
Q2201 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q2202 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q2206 8-729-041-43 TRANSISTOR HN1L02FU(TE85R)
Q2211 8-729-042-58 TRANSISTOR UN9111J-(K8).SO
Q2213 8-729-427-70 TRANSISTOR XP4401-TXE
Q2214 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q2216 8-729-141-48 TRANSISTOR 2SB624-T1BV4
Q2219 8-729-037-72 TRANSISTOR UN9211J-(K8).SO
Q2220 8-729-037-72 TRANSISTOR UN9211J-(K8).SO
Q2901 8-729-037-72 TRANSISTOR UN9211J-(K8).SO
Q3400 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3401 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3402 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3403 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3404 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3405 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3406 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3407 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q3408 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3409 8-729-041-23 TRANSISTOR NDS356AP
Q3410 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q3411 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3414 8-729-041-24 TRANSISTOR NDS355AN
Q3415 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q3416 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
< RESISTOR >
R202 1-218-990-11 SHORT 0
R203 1-218-990-11 SHORT 0
R206 1-218-977-11 RES,CHIP 100K 5% 1/16W
R209 1-218-973-11 RES,CHIP 47K 5% 1/16W
R210 1-218-953-11 RES,CHIP 1K 5% 1/16W
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VC-210
To Next Page
