6-23E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSISTOR >
Q5500 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5501 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5502 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5503 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5504 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5505 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
< RESISTOR >
R5500 1-218-964-11 RES,CHIP 8.2K 5% 1/16W
R5501 1-218-964-11 RES,CHIP 8.2K 5% 1/16W
R5502 1-218-971-11 RES,CHIP 33K 5% 1/16W
R5503 1-218-964-11 RES,CHIP 8.2K 5% 1/16W
R5504 1-218-955-11 RES,CHIP 1.5K 5% 1/16W
R5505 1-218-962-11 RES,CHIP 5.6K 5% 1/16W
R5506 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R5507 1-218-938-11 RES,CHIP 56 5% 1/16W
R5508 1-218-938-11 RES,CHIP 56 5% 1/16W
R5509 1-218-938-11 RES,CHIP 56 5% 1/16W
R5510 1-218-938-11 RES,CHIP 56 5% 1/16W
R5511 1-218-990-11 SHORT 0
< SWITCH >
S5500 1-771-040-21 SWITCH, PUSH (EVF ON/OFF)
< THERMISTOR >
TH5500 1-810-812-21 THERMISTOR, NTC (1608)
************************************************************
MISCELLANEOUS
*************
* 3 1-528-909-11 BATTERY, LITHIUM SECONDARY
4 1-959-018-11 HARNESS (LI-58)
9 1-475-975-11 MICROPHONE UNIT
52 1-694-459-11 TERMINAL BOARD, BATTERY
103 1-959-019-11 HARNESS (PD-107)
104 1-505-862-11 SPEAKER (2.0CM)
105 1-959-017-11 HARNESS (SP-158)
! 121 1-475-711-11 TRANSFORMER UNIT, INVERTER
123 1-475-920-21 SWITCH BLOCK, CONTROL (ME-4781)
161 1-475-919-11 SWITCH BLOCK, CONTROL (FK-4780)
201 8-848-728-01 DEVICE (LSV-620A (SOC)), LENS
206 A-7030-881-A CCD BLOCK ASSY (PC1)
206 A-7030-885-A CCD BLOCK ASSY (PC1E)
208 1-758-202-21 FILTER BLOCK, OPTICAL
D901 8-719-050-98 DIODE LN57.SO
LCD901 8-753-050-08 DCX501BK-1
LCD902 8-753-023-51 LCX027AK-1
M901 A-7048-887-A DRUM ASSY (DEH-11B-R)
M902 8-835-524-04 MOTOR, DC SCD-0101A (CAPSTAN)
M903 A-7010-673-A ASSY, LM MOTOR (LOADING)
! ND901 1-517-800-11 TUBE, FLUORESCENT,COLD CATHODE
! ND902 1-475-980-11 BLOCK, LIGHT GUIDE PLATE
************************************************************
ACCESSORIES
************
1-475-141-21 COMMANDER, REMOTE (RMT-808)
(PC1/PC1E:EXCEPT AEP,UK)
1-475-141-31 COMMANDER, REMOTE (RMT-809)
(PC1E:AEP,UK)
! 1-475-851-21 ADAPTOR, AC (PC1:US,CND)
! 1-475-851-31 ADAPTOR, AC (PC1:E,HK,JE/PC1E)
! 1-555-074-21 CORD, POWER (PC1E:AUS)
1-559-437-11 ADAPTOR, CONVERSION 2P (JE)
1-569-008-21 ADAPTOR, CONVERSION 2P (E,HK,JE)
1-573-291-11 CONNECTOR, CONVERSION 21P(PC1E:AEP,UK)
1-573-856-11 ADAPTOR, CONVERSION 2P (JE)
! 1-690-827-11 CORD SET, POWER (PC1E:AEP)
1-765-080-11 AV CONNECTION CABLE (1.5m)
(PC1/PC1E:EXCEPT AEP,UK)
! 1-769-608-11 CORD, POWER (E,HK)
1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (PC1E:HK)
! 1-775-549-21 CORD, POWER (PC1:US,CND)
! 1-775-843-21 CORD, POWER(WITH FILTER) (PC1E:UK)
1-777-433-21 AV CONNECTION CABLE (1.5m)(PC1E:AEP,UK)
! 1-782-476-11 CORD, POWER (PC1E:CN)
1-783-739-11 CORD, CONNECTION
3-864-274-11 MANUAL, INSTRUCTION (ENGLISH) (PC1)
3-864-274-21 MANUAL, INSTRUCTION (FRENCH) (PC1:CND)
3-864-274-31 MANUAL, INSTRUCTION
(SPANISH/PORTUGUSEE) (PC1:E,HK,JE)
3-864-274-41 MANUAL, INSTRUCTION (CHINESE) (PC1:E/HK)
3-864-274-51 MANUAL, INSTRUCTION (KOREAN) (PC1:JE)
3-864-274-61 MANUAL. INSTRUCTION (KOREAN) (PC1:E)
3-864-275-11 MANUAL, INSTRUCTION (ENGLISH/RUSSIAN)
(PC1E:AEP,UK)
3-864-275-21 MANUAL, INSTRUCTION
(SPANISH/PORTUGUSEE) (PC1:AEP)
3-864-275-31 MANUAL, INSTRUCTION (DUTCH/FRENCH)
(PC1E:AEP)
3-864-275-41 MANUAL, INSTRUCTION (GERMAN/ITALIAN)
(PC1E:AEP)
3-864-275-51 MANUAL, INSTRUCTION (ENGLISH/RUSSIAN)
(PC1E:CN,E,HK,AUS,JE)
3-864-275-61 MANUAL, INSTRUCTION (FRENCH/GERMAN)
(PC1E:CN,E,JE)
3-864-275-71 MANUAL, INSTRUCTION (ARAQBIC/PERSIAN)
(PC1E:CN,E,JE)
3-864-275-81 MANUAL, INSTRUCTION (CHINESE)
(PC1E:CN,E,JE)
3-864-275-91 MANUAL, INSTRUCTION (CHINESE) (PC1E:CN)
VF-125
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Be sure to read “Note on the CCD Imager replacement” on
page 4-10 when changing the CCD Imager.
