5-15
DCR-PC350/PC350E
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
CR-048 FP-994
A-1070-194-A CR-048 BOARD, COMPLETE
**********************
(CN8501 is included in this COMPLETE board.)
< CAPACITOR >
C8500 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN8500 1-816-873-11 CONNECTOR BOARD TO BOARD 60P
CN8501 Not supplied CONNECTOR, MULTIPLE (SOCKET)
(CN8501 is included in this COMPLETE board of CR-048.)
< DIODE >
D8500 8-719-056-61 DIODE MAZS082008SO
D8501 8-719-158-49 DIODE RD12SB2
D8502 8-719-158-49 DIODE RD12SB2
D8503 8-719-158-49 DIODE RD12SB2
D8504 8-719-158-49 DIODE RD12SB2
D8508 8-719-078-02 DIODE 1SS357 (T3SONY1)
< FERRITE BEAD >
FB8501 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB8502 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB8503 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB8504 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< JACK >
J8500 1-694-688-11 TERMINAL, S (S VIDEO)
< LINE FILTER >
LF8500 1-456-681-21 COIL, CHOKE
< RESISTOR >
R8504 1-218-965-11 RES-CHIP 10K 5% 1/16W
R8506 1-216-864-11 SHORT CHIP 0
R8507 1-216-864-11 SHORT CHIP 0
R8512 1-218-965-11 RES-CHIP 10K 5% 1/16W
< TERMINAL >
BT8500 1-694-950-11 TERMINAL BOARD, BATTERY
< VARISTOR >
VD8501 1-801-862-11 VARISTOR, CHIP (1608)
VD8507 1-801-862-11 VARISTOR, CHIP (1608)
VD8509 1-801-862-11 VARISTOR, CHIP (1608)
VD8510 1-801-862-11 VARISTOR, CHIP (1608)
************************************************************
A-1070-200-A FP-994 FLEXIBLE BOARD, COMPLETE
******************************
< SWITCH >
S9400 1-786-179-31 SWITCH, PUSH (1KEY) (PANEL REVERSE)
************************************************************
A-1070-201-A FP-995 FLEXIBLE BOARD, COMPLETE
******************************
< DIODE >
D953 8-719-056-85 DIODE UDZ-TE-17-8.2B
D954 8-719-056-85 DIODE UDZ-TE-17-8.2B
< JACK >
J950 1-778-040-11 JACK, SMALL TYPE (AUDIO/VIDEO)
J951 1-793-995-11 JACK, SUPER SMALL TYPE (LANC)
< RESISTOR >
R901 1-216-864-11 SHORT CHIP 0
************************************************************
A-1070-202-A FP-996 FLEXIBLE BOARD, COMPLETE
******************************
< CAPACITOR >
C9600 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C9601 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< DIODE >
D9600 8-719-079-78 DIODE DCZ2805
D9601 8-719-079-78 DIODE DCZ2805
D9602 8-719-073-01 DIODE MA111-(K8).S0
D9603 8-719-422-64 DIODE MA8062-M
D9604 8-719-064-07 DIODE SML-310LTT86
< IC >
IC9600 8-742-221-00 HYB IC SBX3055-01
< TRANSISTOR >
Q9600 8-729-049-92 TRANSISTOR 2SC5585H-T2L
Q9601 8-729-037-72 TRANSISTOR UN9211J-(TX).SO
< RESISTOR >
R9600 1-216-019-00 RES-CHIP 56 5% 1/10W
R9601 1-216-019-00 RES-CHIP 56 5% 1/10W
R9602 1-216-807-11 METAL CHIP 68 5% 1/10W
R9603 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9604 1-216-805-11 METAL CHIP 47 5% 1/10W
R9605 1-216-819-11 METAL CHIP 680 5% 1/10W
R9606 1-216-295-91 SHORT CHIP 0
************************************************************
FP-995 FP-996
