5-16
DCR-PC350/PC350E
Ref. No. Part No. Description Ref. No. Part No. Description
MS-234
A-1070-197-A MS-234 BOARD, COMPLETE
***********************
< BATTERY >
0 BT800 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C802 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C803 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C804 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C805 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C806 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C807 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C808 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C809 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C810 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C811 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C812 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C814 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C815 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C817 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C818 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C819 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C821 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C823 1-164-227-11 CERAMIC CIP 0.022uF 10% 25V
C824 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C826 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C827 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C830 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C832 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C833 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C835 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C837 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C838 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C839 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C840 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C842 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C843 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN800 1-818-683-21 CONNECTOR, FPC (ZIF) 33P
CN801 1-817-913-11 MEMORY STICK DUO CONNECTOR
(MEMORY STICK DUO CONNECTOR)
< DIODE >
D800 6-500-506-01 DIODE TLRMV1021 (T15SOY, F)
< FERRITE BEAD >
FB800 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB801 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB802 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB803 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC800 8-759-638-50 IC AN2901FHQEBV
IC801 6-705-686-01 IC TK11129CSCL-G
< JACK >
J800 1-784-943-71 JACK (SMALL TYPE) (MIC)
< COIL >
L800 1-469-528-91 INDUCTOR 100uH
< RESISTOR >
R800 1-218-968-11 RES-CHIP 18K 5% 1/16W
R801 1-218-971-11 RES-CHIP 33K 5% 1/16W
R802 1-218-965-11 RES-CHIP 10K 5% 1/16W
R803 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R804 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R805 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R808 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R809 1-218-953-11 RES-CHIP 1K 5% 1/16W
R810 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R811 1-218-953-11 RES-CHIP 1K 5% 1/16W
R812 1-218-953-11 RES-CHIP 1K 5% 1/16W
R816 1-218-969-11 RES-CHIP 22K 5% 1/16W
R818 1-218-969-11 RES-CHIP 22K 5% 1/16W
R820 1-218-990-11 SHORT CHIP 0
R821 1-218-990-11 SHORT CHIP 0
R823 1-218-966-11 RES-CHIP 12K 5% 1/16W
R824 1-218-966-11 RES-CHIP 12K 5% 1/16W
R825 1-218-971-11 RES-CHIP 33K 5% 1/16W
R826 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R827 1-218-968-11 RES-CHIP 18K 5% 1/16W
R828 1-218-971-11 RES-CHIP 33K 5% 1/16W
R830 1-208-912-11 METAL CHIP 11K 0.5% 1/16W
R831 1-208-701-11 METAL CHIP 5.6K 0.5% 1/16W
R833 1-208-912-11 METAL CHIP 11K 0.5% 1/16W
R834 1-218-953-11 RES-CHIP 1K 5% 1/16W
R835 1-218-956-11 RES-CHIP 1.8K 5% 1/16W
< SWITCH >
S800 1-771-138-82 SWITCH, KEY BOARD (RESET)
< VARISTOR >
VDR804 1-801-862-11 VARISTOR, CHIP (1608)
VDR805 1-801-925-21 VARISTOR, CHIP (1608)
VDR806 1-801-925-21 VARISTOR, CHIP (1608)
************************************************************
CAUTION :
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
The components identified by mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce portant le numéro spécifié.
0 0
