5-17
DCR-PC350/PC350E
Ref. No. Part No. Description Ref. No. Part No. Description
A-1070-199-A PD-225 BOARD, COMPLETE
**********************
< CAPACITOR >
C602 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C604 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C607 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C608 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C609 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C611 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C612 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C613 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C615 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C616 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C617 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C618 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C619 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C622 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C624 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C625 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C626 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C627 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C630 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C631 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C632 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
< CONNECTOR >
CN601 1-793-224-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN602 1-573-915-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN603 1-573-346-21 CONNECTOR, FFC/FPC 6P
CN605 1-573-364-11 CONNECTOR, FFC/FPC 24P
CN606 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D602 8-719-073-01 DIODE MA111-(K8).S0
D604 8-719-074-67 DIODE EDZ-TE61-5.6B
< FERRITE BEAD >
FB601 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC601 8-739-093-13 IC NJM12904V (TE2)
IC602 8-752-109-72 IC CXM3006R
< COIL >
L601 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L602 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L603 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
< TRANSISTOR >
Q601 8-729-427-42 TRANSISTOR XP4211
Q602 8-729-427-12 TRANSISTOR XP4111
Q603 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q604 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q605 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q606 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q607 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q608 6-550-119-01 TRANSISTOR DTC144EMT2L
Q609 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q610 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R601 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R602 1-216-864-11 SHORT CHIP 0
R603 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R604 1-216-864-11 SHORT CHIP 0
R605 1-216-864-11 SHORT CHIP 0
R606 1-216-864-11 SHORT CHIP 0
R608 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R609 1-218-989-11 RES-CHIP 1M 5% 1/16W
R610 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R611 1-218-975-11 RES-CHIP 68K 5% 1/16W
R613 1-218-977-11 RES-CHIP 100K 5% 1/16W
R615 1-218-949-11 RES-CHIP 470 5% 1/16W
R616 1-220-206-11 RES-CHIP 91K 5% 1/16W
R618 1-218-973-11 RES-CHIP 47K 5% 1/16W
R619 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R620 1-218-973-11 RES-CHIP 47K 5% 1/16W
R621 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R622 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R623 1-218-953-11 RES-CHIP 1K 5% 1/16W
R625 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R626 1-218-965-11 RES-CHIP 10K 5% 1/16W
R629 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R631 1-218-953-11 RES-CHIP 1K 5% 1/16W
R632 1-218-973-11 RES-CHIP 47K 5% 1/16W
R633 1-218-978-11 RES-CHIP 120K 5% 1/16W
R634 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R635 1-218-989-11 RES-CHIP 1M 5% 1/16W
R637 1-218-960-11 RES-CHIP 3.9K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-234-369-21 RES, NETWORK 10X4 (1005)
************************************************************
A-1070-195-A SE-151 BOARD, COMPLETE
**********************
< CAPACITOR >
C2500 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2501 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2502 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C2503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2506 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2508 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2510 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C2511 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C2512 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2513 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C2514 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C2515 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2516 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2517 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
PD-225 SE-151
