5-18
DCR-PC350/PC350E
Ref. No. Part No. Description Ref. No. Part No. Description
C2519 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2520 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2521 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
< CONNECTOR >
CN2500 1-816-644-31 FFC/CONNECTOR, FPC (LIF) 12P
CN2501 1-815-098-11 CONNECTOR, FPC (ZIF) 21P
CN2502 1-818-043-21 CONNECTOR, FFC/FPC 10P
CN2503 1-816-873-11 CONNECTOR BOARD TO BOARD 60P
CN2504 1-794-376-21 PIN, CONNECTOR 4P
< DIODE >
D2500 8-719-074-67 DIODE EDZ-TE61-5.6B
D2501 6-500-875-01 DIODE E1S35-AW0C7-01-A3
D2502 6-500-289-01 DIODE MAZW082H0LS0
D2503 6-500-289-01 DIODE MAZW082H0LS0
D2504 6-500-776-01 DIODE MAZW068H0LS0
< FERRITE BEAD >
FB2501 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB2502 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB2503 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB2504 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB2505 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< IC >
IC2500 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L2500 1-469-570-11 INDUCTOR 10uH
< RESISTOR >
R2502 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2503 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2508 1-216-864-11 SHORT CHIP 0
R2509 1-216-864-11 SHORT CHIP 0
R2510 1-216-295-91 SHORT CHIP 0
R2512 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2513 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2514 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2515 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2516 1-218-969-11 RES-CHIP 22K 5% 1/16W
R2517 1-218-969-11 RES-CHIP 22K 5% 1/16W
R2518 1-218-969-11 RES-CHIP 22K 5% 1/16W
R2519 1-218-969-11 RES-CHIP 22K 5% 1/16W
R2520 1-218-990-11 SHORT CHIP 0
R2521 1-218-990-11 SHORT CHIP 0
R2522 1-218-990-11 SHORT CHIP 0
R2523 1-218-990-11 SHORT CHIP 0
R2524 1-218-990-11 SHORT CHIP 0
R2525 1-218-990-11 SHORT CHIP 0
R2530 1-218-990-11 SHORT CHIP 0
R2531 1-218-990-11 SHORT CHIP 0
< SENSOR >
SE2500 1-476-807-31 SENSOR, ANGULAR VELOCITY (YAW)
SE2501 1-476-807-41 SENSOR, ANGULAR VELOCITY (PITCH)
************************************************************
A-1070-198-A ST-108 BOARD, COMPLETE
**********************
< CAPACITOR >
C500 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C502 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C505 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
< CONNECTOR >
CN500 1-816-595-31 CONNECTOR, FPC (ZIF) 23P
CN501 1-815-333-11 CONNECTOR, FPC (ZIF) 33P
CN502 1-817-548-11 CONNECTOR, FPC 6P
< DIODE >
D500 8-719-073-01 DIODE MA111-(K8).S0
D9605 6-500-289-01 DIODE MAZW082H0LS0
< IC >
IC500 6-703-635-01 IC TND721MH5-S-TL-E
< TRANSISTOR >
Q500 8-729-048-75 TRANSISTOR CPH3109-TL-E
Q501 8-729-426-24 TRANSISTOR XP1211-TXE
Q502 8-729-053-74 TRANSISTOR CY25AAJ-8-T13-F00R
< RESISTOR >
R501 1-216-805-11 METAL CHIP 47 5% 1/10W
R502 1-216-837-11 METAL CHIP 22K 5% 1/10W
R503 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R504 1-216-816-11 METAL CHIP 390 5% 1/10W
R505 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R506 1-216-805-11 METAL CHIP 47 5% 1/10W
R507 1-216-857-11 METAL CHIP 1M 5% 1/10W
R508 1-218-953-11 RES-CHIP 1K 5% 1/16W
************************************************************
A-1070-196-A VP-060 BOARD, COMPLETE
**********************
< CONNECTOR >
CN8600 1-816-924-11 CONNECTOR BOARD TO BOARD 40P
CN8601 1-816-650-31 FFC/CONNECTOR, FPC (LIF) 24P
CN8602 1-816-654-31 FFC/CONNECTOR, FPC (LIF) 6P
< DIODE >
D8601 8-719-422-64 DIODE MA8062-M
D8602 8-719-422-64 DIODE MA8062-M
D8603 8-719-422-64 DIODE MA8062-M
D8604 8-719-422-64 DIODE MA8062-M
< FERRITE BEAD >
FB8601 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB8602 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB8603 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
SE-151 ST-108 VP-060
