SY-278 BOARD (A SIDE)
SY-278 board
n
Do not change the setting of switches when the “factory use” is shown in the description.
Ref No. Description Factory Setting
S101 Push this switch when resetting the system control. —
S201-1 factory use OFF
S201-2 factory use OFF
S201-3 factory use OFF
S201-4 factory use OFF
S201-5 factory use OFF
S201-6 factory use OFF
S201-7, 8 Destination setting Destination bit-7 bit-8 —
UC OFF OFF
J ON OFF
CE OFF ON
