7-58
DSR-2000/2000P
7-20. MIC Holder Assembly Replacement
Outline
Replacement
Removing the MD cover
Removing the MIC assembly
Replacing the MIC holder assembly
Reattaching the MIC assembly
Reattaching the MD cover
Note
Prepare new stop washers when replacing the MIC holder.
Stop washer (1.2) : 3-559-408-11 x 2 (for mounting the MIC holder assembly)
Stop washer (1.5) : 3-669-465-01 x 1 (for mounting the MIC assembly)
Do avoid touching the terminal on the MIC holder and wiping it with cleaning fluid.
When need cleaning, wipe it carefully with a soft dry cloth.
Use care not to lose a poly-slider washer between the base plate and the MIC
assembly.
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the bottm panel. (Refer to Section 3-3.)
5. Remove the right side panel. (Refer to Section 3-3.)
6. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.5 : J-6082-231-A
. Washer mounting fixture Ø1.2 : J-6082-232-A
. Tweezers
7-20. MIC Holder Assembly Replacement
