Sony DSR-2000 - M Stop Solenoid Assembly Replacement

7-31
DSR-2000/2000P
7-10. M Stop Solenoid Assembly Replacement
Outline
Replacement
Removing the MD cover
Removing the stopper driving plate (M) assembly
Replacing the M stop solenoid assembly
Reattaching the stopper driving plate (M) assembly
Reattaching the MD cover
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the bottom panel. (Refer to Section 3-3.)
4. Remove the right side panel. (Refer to Section 3-3.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver’s bit (for M2) : J-6325-380-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Screw locking compound : 7-432-114-11
7-10. M Stop Solenoid Assembly Replacement
