6-1. Periodic Inspection List
The following table shows the reference parts replacement time which is not the warranty time of parts.
Refer to the following table to establish the periodic inspection schedule which realizes the full performance and
function of a unit and to extend life of a tape. The actual parts replacement period depend on the operating
environment and conditions of a unit.
: Part replace : Check (Adjustment) O : Cleaning
Inspection items Hours meter Inspection time (Hours)
Item Part No. Name Menu No. 2000 4000 6000 8000
Drum assembly A-8323-775-A DEH-16A-R H02
Tape drive system blocks
Pinch solenoid A-8279-203- Pinch Solenoid assembly H02 ___
Brake solenoid 1-454-930-21 Solenoid plunger H02 ___
Reel motor (T) 8-835-636-51 DC motor (SRD14A/J-RP) H02
Reel motor (S) 8-835-637-51 DC motor (SRD15A/J-RP) H02
Loading motor A-8279-202- LD Motor assembly H02 _ _
Reel sift motor A-8279-204- RS motor assembly H02 _ _
T reel brake shoe A-8324-480- Brake (T) assembly H02
S reel brake shoe A-8324-481- Brake (S) assembly H02
Head cleaner solenoid 1-454-942-31 Plunger solenoid H02 ___
M stop solenoid 1-454-932-11 Plunger solenoid H02 ___
Tape path system blocks
Capstan motor 8-835-619-51 DC motor (SCD16A/J-RP) H02 O O O O
Pinch roller A-8279-044- Pinch limiter assembly H02
Guide roller T2 A-8279-024- Shuttle (R) assembly H02 O O O O
Guide roller T3 A-8279-026- T drawer arm assembly H02 O O O O
Guide roller T4 A-8279-400- TG-8 arm assembly H02 O O O O
Guide roller S2 A-8279-023- Shuttle (L) assembly H02 O O O O
Guide roller S3 A-8323-655- Tension regulator assembly H02 O O O O
Guide roller S4 A-8279-399- TG-1 arm assembly H02 O O O O
Tape running surface —— —— —— O O O O
(including tape cleaner)
Head cleaner X-3605-655-1 HC roller assembly
Others
Cassette memory terminal A-8323-659- MIC holder assembly H02 O O O O
