7-7. Pinch Solenoid Assembly Replacement
Outline
Replacement
Removing the pinch limiter assembly.
Disconnecting the connector.
Replacing the pinch solenoid assembly.
Reconnecting the connector.
Reattaching the pinch limiter assembly.
Adjustment after replacement
Checking the tape path adjustment
Note
Without removal/reattachment of the pinch limiter assembly, the pinch solenoid
assembly cannot be replaced.
Therefore prepare a new stop washer for replacing the pinch limiter assembly.
Stop washer (1.5) : 3-669-465-01 x 1
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.5 : J-6082-231-A
. Tweezers
