Sony DSR-2000 - Video Adjustment

10-5
DSR-2000/2000P
10-3. Video Adjustment
[Switch Setting]
For NTSC
This setting should be fixed in position unless otherwise specified.
LOCAL/REMOTE ; LOCAL PROCESS CONTROL ; LOCAL
CHARACTER ; ON VIDEO
MENU ITEM 713-1, INPUT LEVEL ; 0.0 % CHROMA
MENU ITEM 713-2, OUTPUT LEVEL ; 0.0 % SET UP ; PRESET
Y/C DELAY
HUE
For PAL
LOCAL/REMOTE ; LOCAL VIDEO
CHARACTER ; ON Y/C DELAY
; PRESET
PROCESS CONTROL ; LOCAL
[Connection]
Connect some equipment as following unless otherwise specified.
(Connection 1)
(Connection 2)







10-3. Video Adjustment



EXT REF
CH-1
CH-2
CH-3
WFM or Oscilloscope
(Terminated at 75 Z)
COMPONENT OUT
TP
REF. VIDEO IN
(75 Z : OFF)
DSR-2000/2000P
COMPONENT IN
Oscilloscope
Video signal generator
(NTSC : TSG-130A)
(PAL : TSG-131A)
BB
Oscilloscope
A
EXT REF
WFM
(VIDEO OUT 3)
(VIDEO OUT 2)
REF.VIDEO OUT
S VIDEO OUT
VIDEO OUT 1
Video signal genelator
(NTSC : TSG-130A)
(PAL : TSG-131A)
TP
REF. VIDEO IN
(75 Z : OFF)
DSR-2000/2000P
VIDEO IN (75 Z : ON)
S VIDEO IN
BB
