7-49
DSR-2000/2000P
7-16. Capstan Motor Replacement
7-16. Capstan Motor Replacement
Outline
Replacement
Removing the MD cover
Replacing the capstan motor
Reattaching the MD cover
Cleaning the capstan shaft
Adjustment after replacement
CAPSTAN ONLY adjustment
Checking the tape path adjustment
Preparation
1. Set the unit in to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the bottom panel. (Refer to Section 3-3.)
5. Remove the right side panel. (Refer to Section 3-3.)
6. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
To Next Page
