Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
110
HCD-M333
< JUMPER RESISTOR >
JR602 1-216-864-11 METAL CHIP 0 5% 1/16W
< JUMPER RESISTOR >
JW630 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L601 1-410-780-11 INDUCTOR 27MH
L651 1-410-780-11 INDUCTOR 27MH
< TRANSISTOR >
Q639 8-729-040-20 TRANSISTOR RT1P137L-TP
Q640 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q641 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q642 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q643 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q680 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q681 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q691 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q692 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q693 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q694 8-729-116-57 TRANSISTOR 2SB1068TP-K
< RESISTOR >
R601 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R603 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R604 1-216-833-11 METAL CHIP 10K 5% 1/16W
R605 1-216-841-11 METAL CHIP 47K 5% 1/16W
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R607 1-216-833-11 METAL CHIP 10K 5% 1/16W
R609 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R610 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R611 1-216-837-11 METAL CHIP 22K 5% 1/16W
R630 1-216-857-11 METAL CHIP 1M 5% 1/16W
R631 1-216-837-11 METAL CHIP 22K 5% 1/16W
R632 1-216-821-11 METAL CHIP 1K 5% 1/16W
R633 1-216-833-11 METAL CHIP 10K 5% 1/16W
R635 1-216-809-11 METAL CHIP 100 5% 1/16W
R640 1-216-833-11 METAL CHIP 10K 5% 1/16W
R641 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R642 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
0R643 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0R644 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R645 1-216-836-11 METAL CHIP 18K 5% 1/16W
R646 1-216-836-11 METAL CHIP 18K 5% 1/16W
R648 1-216-864-11 METAL CHIP 0 5% 1/16W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R652 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R653 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R654 1-216-833-11 METAL CHIP 10K 5% 1/16W
R655 1-216-841-11 METAL CHIP 47K 5% 1/16W
R656 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R657 1-216-833-11 METAL CHIP 10K 5% 1/16W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R660 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R661 1-216-837-11 METAL CHIP 22K 5% 1/16W
R680 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R681 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R682 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R683 1-216-819-11 METAL CHIP 680 5% 1/16W
R684 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R685 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R686 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R687 1-216-841-11 METAL CHIP 47K 5% 1/16W
R688 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R689 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R690 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R691 1-216-833-11 METAL CHIP 10K 5% 1/16W
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R693 1-216-841-11 METAL CHIP 47K 5% 1/16W
R694 1-216-837-11 METAL CHIP 22K 5% 1/16W
R695 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VARIABLE RESISTOR >
RV602 1-241-765-11 RES, ADJ, CARBON 22K
RV603 1-241-768-11 RES, ADJ, CARBON 220K
RV652 1-241-765-11 RES, ADJ, CARBON 22K
RV653 1-241-768-11 RES, ADJ, CARBON 220K
< TRANSFORMER >
T601 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
1-686-403-11 TRANS BOARD (EXCEPT CND)
************
1-689-658-11 TRANS BOARD (CND ONLY)
************
< CAPACITOR >
0C991 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
0C994 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
< CONNECTOR >
* CN991 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN992 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
< DIODE >
D991 8-719-800-76 DIODE 1SS133T-91 (CND)
D991 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT CND)
< TRANSISTOR >
Q991 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R991 1-249-417-11 CARBON 1K 5% 1/4W F
R992 1-249-429-11 CARBON 10K 5% 1/4W
R996 1-249-397-11 CARBON 22 5% 1/4W F
R997 1-219-237-91 SOLID 3.3M 20% 1/2W
(CND)
< RELAY >
0RY991 1-755-467-11 RELAY (POWER)
TC TRANS
Ver 1.1 2003.05
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
