27
HCD-M333
3-19. Base Unit (BU-30BBD61B)
1
floating screw
(+PTPWH M2.6)
3
chassis (55D)
2
Remove the base unit (BU-30BBD61B
in the direction of the arrow
A
.
A
3-20. Optical Pick Up (BU-30B Assy)
8
two insulators
9
two insulators
qs
BD (CD) board
2
floating screw
(+PTPWH M2.6)
3
floating screw
(+PTPWH M2.6)
4
two floating screws
(+PTPWH M2.6)
5
bu holder (BU-30)
6
two compression springs
7
two compression springs
qd
BU-30B assy
qa
Remove the two soldering
0
Remove the two solderings
1
flat type wire (16 core)
