Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
97
HCD-M333
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
•Abbreviation
AUS: Australian model
CH : Chinese model
CND : Canadian model
HK : Hong Kong model
SECTION 8
ELECTRICAL PARTS LIST
A-4732-583-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C800 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C802 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C803 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C804 1-126-967-11 ELECT 47uF 20.00% 50V
C805 1-136-169-00 FILM 0.22uF 5.00% 50V
C806 1-136-169-00 FILM 0.22uF 5.00% 50V
C807 1-136-169-00 FILM 0.22uF 5.00% 50V
C808 1-136-169-00 FILM 0.22uF 5.00% 50V
C809 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C810 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C811 1-107-713-11 ELECT 4.7uF 20.00% 50V
C813 1-126-963-11 ELECT 4.7uF 20.00% 50V
C820 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C821 1-126-963-11 ELECT 4.7uF 20.00% 50V
C822 1-126-965-91 ELECT 22uF 20.00% 50V
C823 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C831 1-126-964-11 ELECT 10uF 20.00% 50V
C832 1-104-665-11 ELECT 100uF 20.00% 10V
C833 1-126-961-11 ELECT 2.2uF 20.00% 50V
C834 1-104-665-11 ELECT 100uF 20.00% 10V
C845 1-126-964-11 ELECT 10uF 20.00% 50V
C846 1-126-965-91 ELECT 22uF 20.00% 50V
C852 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C853 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C854 1-126-967-11 ELECT 47uF 20.00% 50V
C855 1-136-169-00 FILM 0.22uF 5.00% 50V
C856 1-136-169-00 FILM 0.22uF 5.00% 50V
C857 1-136-169-00 FILM 0.22uF 5.00% 50V
C858 1-136-169-00 FILM 0.22uF 5.00% 50V
C859 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C860 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C861 1-107-713-11 ELECT 4.7uF 20.00% 50V
C863 1-126-963-11 ELECT 4.7uF 20.00% 50V
C870 1-107-717-11 ELECT 47uF 20.00% 50V
C891 1-128-549-11 ELECT 3300uF 20.00% 35V
C892 1-128-549-11 ELECT 3300uF 20.00% 35V
C893 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C894 1-127-876-11 CERAMIC 0.01uF 10% 50V
C895 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
< CONNECTOR >
CN802 1-568-830-11 CONNECTOR, FFC 11P
* CN803 1-564-518-11 PLUG, CONNECTOR 3P
* CN804 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN805 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D820 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-988-61 DIODE 1SS355TE-17
D822 8-719-988-61 DIODE 1SS355TE-17
D823 8-719-017-67 DIODE MA8068-H-TX
D831 8-719-988-61 DIODE 1SS355TE-17
D841 8-719-988-61 DIODE 1SS355TE-17
D842 8-719-988-61 DIODE 1SS355TE-17
D843 8-719-988-61 DIODE 1SS355TE-17
D851 8-719-988-61 DIODE 1SS355TE-17
D871 8-719-988-61 DIODE 1SS355TE-17
D881 8-719-988-61 DIODE 1SS355TE-17
D890 8-719-988-61 DIODE 1SS355TE-17
D891 8-719-988-61 DIODE 1SS355TE-17
D892 8-719-988-61 DIODE 1SS355TE-17
D893 8-719-988-61 DIODE 1SS355TE-17
D894 8-719-988-61 DIODE 1SS355TE-17
D895 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
EP802 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC803 6-703-084-01 IC STK403-030
< COIL >
L801 1-422-009-13 COIL, AIR-CORE
L851 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q820 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
Q821 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q822 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q823 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q824 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q831 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q832 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q833 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q834 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q835 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q836 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
AMP
Ver 1.1 2003.05
