Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
98
HCD-M333
Q837 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q841 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q842 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q845 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q851 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q871 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q872 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q873 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q874 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q875 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q881 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q882 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
< RESISTOR >
R801 1-216-049-11 RES-CHIP 1K 5% 1/10W
R802 1-216-073-91 RES-CHIP 10K 5% 1/10W
R803 1-216-049-11 RES-CHIP 1K 5% 1/10W
R804 1-216-091-00 METAL CHIP 56K 5% 1/10W
R805 1-216-361-00 METAL OXIDE 0.22 5% 2W
R806 1-260-076-11 CARBON 10 5% 1/2W
R807 1-260-076-11 CARBON 10 5% 1/2W
R808 1-260-076-11 CARBON 10 5% 1/2W
R809 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R810 1-216-049-11 RES-CHIP 1K 5% 1/10W
R811 1-216-077-91 RES-CHIP 15K 5% 1/10W
R812 1-216-097-11 RES-CHIP 100K 5% 1/10W
R813 1-216-097-11 RES-CHIP 100K 5% 1/10W
R814 1-249-438-11 CARBON 56K 5% 1/4W
R816 1-215-864-00 METAL OXIDE 150 5% 1W
R817 1-215-864-00 METAL OXIDE 150 5% 1W
R818 1-216-097-11 RES-CHIP 100K 5% 1/10W
R820 1-216-081-00 METAL CHIP 22K 5% 1/10W
R821 1-216-049-11 RES-CHIP 1K 5% 1/10W
R822 1-216-089-91 RES-CHIP 47K 5% 1/10W
R823 1-216-073-91 RES-CHIP 10K 5% 1/10W
R824 1-216-049-11 RES-CHIP 1K 5% 1/10W
R825 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R826 1-216-089-91 RES-CHIP 47K 5% 1/10W
R827 1-216-097-11 RES-CHIP 100K 5% 1/10W
R828 1-249-425-11 CARBON 4.7K 5% 1/4W F
R829 1-249-425-11 CARBON 4.7K 5% 1/4W F
R830 1-216-097-11 RES-CHIP 100K 5% 1/10W
R831 1-216-097-11 RES-CHIP 100K 5% 1/10W
R832 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R833 1-249-425-11 CARBON 4.7K 5% 1/4W F
R834 1-216-085-91 RES-CHIP 33K 5% 1/10W
R835 1-216-081-00 METAL CHIP 22K 5% 1/10W
R836 1-216-073-91 RES-CHIP 10K 5% 1/10W
R837 1-216-073-91 RES-CHIP 10K 5% 1/10W
R839 1-216-097-11 RES-CHIP 100K 5% 1/10W
R840 1-216-089-91 RES-CHIP 47K 5% 1/10W
R842 1-216-073-91 RES-CHIP 10K 5% 1/10W
R843 1-216-049-11 RES-CHIP 1K 5% 1/10W
R845 1-216-085-91 RES-CHIP 33K 5% 1/10W
R846 1-216-073-91 RES-CHIP 10K 5% 1/10W
R847 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
0R848 1-212-881-11 FUSIBLE 100 5% 1/4W
0R849 1-202-972-61 FUSIBLE 1 5% 1/4W
0R850 1-202-972-61 FUSIBLE 1 5% 1/4W
R851 1-216-049-11 RES-CHIP 1K 5% 1/10W
R852 1-216-073-91 RES-CHIP 10K 5% 1/10W
R853 1-216-049-11 RES-CHIP 1K 5% 1/10W
R854 1-216-091-00 METAL CHIP 56K 5% 1/10W
R855 1-216-361-00 METAL OXIDE 0.22 5% 2W
R856 1-260-076-11 CARBON 10 5% 1/2W
R857 1-260-076-11 CARBON 10 5% 1/2W
R858 1-260-076-11 CARBON 10 5% 1/2W
R859 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R860 1-216-049-11 RES-CHIP 1K 5% 1/10W
R861 1-216-077-91 RES-CHIP 15K 5% 1/10W
R862 1-216-097-11 RES-CHIP 100K 5% 1/10W
R863 1-216-097-11 RES-CHIP 100K 5% 1/10W
R864 1-249-437-11 CARBON 47K 5% 1/4W
R866 1-215-864-00 METAL OXIDE 150 5% 1W
R867 1-215-864-00 METAL OXIDE 150 5% 1W
R868 1-216-097-11 RES-CHIP 100K 5% 1/10W
R871 1-216-081-00 METAL CHIP 22K 5% 1/10W
R872 1-216-097-11 RES-CHIP 100K 5% 1/10W
R873 1-216-049-11 RES-CHIP 1K 5% 1/10W
R874 1-216-049-11 RES-CHIP 1K 5% 1/10W
R875 1-216-073-91 RES-CHIP 10K 5% 1/10W
R876 1-216-073-91 RES-CHIP 10K 5% 1/10W
R879 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-417-11 CARBON 1K 5% 1/4W F
R881 1-260-088-11 CARBON 120 5% 1/2W
R882 1-216-073-91 RES-CHIP 10K 5% 1/10W
R883 1-216-073-91 RES-CHIP 10K 5% 1/10W
R884 1-216-073-91 RES-CHIP 10K 5% 1/10W
R885 1-216-097-11 RES-CHIP 100K 5% 1/10W
< RELAY >
RY801 1-515-921-11 RELAY (SPEAKER PROTECT)
< THERMISTOR(POSITIVE) >
THP841 1-807-796-11 THERMISTOR
< TERMINAL >
TM801 1-816-048-11 TERMINAL BOARD (SPEAKER L/R)
************************************************************
A-4727-463-A BD (CD) BOARD, COMPLETE
***********************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
BD (CD)AMP
Ver 1.1 2003.05
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
