Sony HCD-M333 - 3-2. Cassette Mechanism Deck; 3-3. Front Panel Section

18
HCD-M333
3-3. Front Panel Section
2 flat type wire
(19 core) (CN108)
1 connector (CNP804
)
5 front panel section
4 two screws (BVTP 3 × 8)
3 screw
(BVTP 3
× 8)
3-2. Cassette Mechanism Deck
5 two screws (BVTP 3 × 8)
1 two screws (KTP 2 × 8)
6 two screws (BVTP 3 × 8)
7 two screws (BVTT 2.6 × 5)
0
qa
qd
2
screw (BVTP 3 × 8)
4 TC board
8 shield (tc2)
qs torsion spring (tc)
9 tape mechanism deck
qf lid (TC) assy
case (T)
3 flat type wire
(8 core) (CN602)
