24
HCD-M333
3-13. Mini Disc Device (KMS-262E)
1
screw
(+B (P) TRI 2
×
6 CZN)
3
screw
(+B (P) TRI 2
×
6 CZN
5
two screws
(+KTP 2
×
6)
6
main shaft
7
flexible board
8
Mini disc device (KMS-262E)
2
base (BU-D)
4
base (BU-A)
3-14. POWER Board, Tuner (FM/AM)
2
flat type wire (11 core) (CN1)
0
connector (CN971)
3
tuner (FM/AM)
qa
POWER board
9
connector (CN997)
7
connector (CN984)
5
6
8
connector (CN981)
1
screw (BVTP 3
×
8
4
screw (BVTT 3
×
6)
