Sony HCD-M333 - IC401 BH6519 FS-E2; IC803 CY24115-2 SCT

80
HCD-M333
IC401 BH6519FS-E2
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
GND
VG
IN4R
IN4F
VM4
OUT4F
PGND4
OUT4R
VM34
OUT3R
PGND3
OUT3F
VM3
IN3F
IN3R
PSB
CAPA– CAPA+ IN2R IN2F VM2 OUT2F PGND2 OUT2R VM12 OUT1R PGND1 OUT1F VM1 IN1F IN1R V
DD
CHARGE
PUMP.
OSC
INTERFACE
AMP
INTERFACE
AMP
AMP
INTERFACE
PREDRIVEPREDRIVE
PREDRIVEPREDRIVE
AMP
INTERFACE
AMPAMPAMP
VDD
PSB
AMP
IC803 CY24115-2SCT
1
2
3
4
8
7
6
5
XOUT
FS1
FS0
CLKA
XIN
VCC
CLKSEL
GND
OSC
Q
P
‡
OUTPUT
DIVIDERS
FREQUENCY
TABLE
VCO
PLL
