Sony HDCE-TX30 - Page 10

6
LED
Ref. No.
Name
Color
Description
Normal State (Power On)
D0201
TDIS_A
Red
Factory use
Inconstant
D0202
TFAULT_A
Red
Factory use
Inconstant
D0203
MOD ABS_A
Red
Factory use
Inconstant
D0204
RX_LOS_A
Red
Factory use
Inconstant
D0205
TDIS_B
Red
Factory use
Inconstant
D0206
TFAULT_B
Red
Factory use
Inconstant
D0207
MOD ABS_B
Red
Factory use
Inconstant
D0208
RX_LOS_B
Red
Factory use
Inconstant
D0401
PGOOD
Green
This LED lights when the power is supplied to the board.
On
D0601
BiBi-LED7
Green
Factory use
Inconstant
D0602
BiBi-LED6
Green
Factory use
Inconstant
D0603
BiBi-LED5
Green
Factory use
Inconstant
D0604
BiBi-LED4
Green
Factory use
Inconstant
D0605
BiBi-LED3
Green
Factory use
Inconstant
D0606
BiBi-LED2
Green
Factory use
Inconstant
D0607
BiBi-LED1
Green
Factory use
Inconstant
D0608
BiBi-LED0
Green
Factory use
Inconstant
D1201
NET2_CONF_DONE
Red
This LED goes out when NET2_FPGA (IC002) is
normally completed configuration.
Off
D1601
NENE-LED7
Green
Factory use
Inconstant
D1602
NENE-LED6
Green
Factory use
Inconstant
D1603
NENE-LED5
Green
Factory use
Inconstant
D1604
NENE-LED4
Green
Factory use
Inconstant
D1605
NENE-LED3
Green
Factory use
Inconstant
D1606
NENE-LED2
Green
Factory use
Inconstant
D1607
NENE-LED1
Green
Factory use
Inconstant
D1608
NENE-LED0
Green
Factory use
Inconstant
D2101
NET1-CONF_DONE
Red
This LED goes out when NET1_FPGA (IC001) is
normally completed configuration.
Off
