Sony HDCE-TX30 - Filter

36
2-4-5. Filter
Preparation
1. Remove the top cover. (Refer to “2-2. Top Cover”.)
2. Remove the NET-37 board assembly. (Refer to “2-3. NET-37 Board Assembly”.)
3. Remove the front panel assembly. (Refer to “2-4. Front Panel Assembly”.)
4. Remove the LE-436 board. (Refer to “2-4-1. LE-436 Board”.)
Procedure
1. Remove the cushion (T).
Projections
Cushion (T)
Holes
Holes
