Sony HDCE-TX30 - DC Fans

86
DC Fans
No. Part No. SP Description
401 A-2189-820-A s LEMO CONNECTOR ASSY-A(FXW)EXP
402 A-5010-103-A s CN-4132_MOUNT
403 1-838-045-12 s OPTICAL MULTI CABLE ASSEMBLY
404 1-855-432-11 s FAN, DC (60 SQUARE)
405 1-855-526-11 s DC FAN (60 X15)
406 1-968-193-31 s HARNESS(COAXIAL CABLE)
407 4-098-033-01 s SADDLE WIRE (C)
408 4-382-854-01 s SCREW (M3X8), P, SW (+)
409 4-559-446-02 s SCREW, +P2.6X5 NEW TRUSTER
410 4-689-064-01 s CUSHION, FAN
411 4-748-474-01 s BRACKET, LEMO CN
412 5-012-833-01 s CUSSION , FAN (60X25)
413 5-016-829-01 s FPC CLAMP
To VIF-82 board
To VIF-82 board
To VIF-82 board
To VIF-82 board
T
o VIF-82 board
a
a
T
o VIF-82 board
S/N: 10001 and higher
S/N: 30001 and higher
Refer to “Cassis”
408
406
410
412
412
413
408
404
405
409
411
408
408
408
408
403
401
408
408
412
408
404
412
410
408
402
407
408
!
!
!
!
