9 Technical data
96 SOREDEX
206718 rev 9
Unit data
Protection against electric shock Class I
Degree of protection Type B applied with no conductive connection to the
patient
Protection against the ingress of
liquids
IP20
Disinfection methods -
mild soapy water (non-abrasive)
- non-alcohol based disinfectant for the chin rest
- disposable plastic covers for bite block, chin rest and
chin support
For use In environments where no flammable anaesthetics nor
flammable cleaning agents are present
Mode of operation continuous operation/intermittent loading
Safety IEC 60601-1
Power supply Mains plug connection
Tube head assembly
Tube head assembly type THA 300
Tube type Toshiba D-052SB, D-054SB-C
Stationary W anode
Tube voltage 57 - 90 kV
In some countries, min. kV limited to 60 kV
Max. tube current 16 mA
In some countries, max. mA limited to 15 mA
Max. electric output 1,44 kW
Target angle 5 degrees
Focal spot 0,5 x 0,5 mm (according to IEC 60336/2005)
Nominal anode input 1750 W
Reference axis In the middle of the panoramic sensor’s active area
Max. anode heat content 35 kJ
Max. X-ray tube assembly heat
content
385 kJ
Max. continuous heat dissipation of
the X-ray tube assembly
38 W
Total filtration min. 3.2 mm Al, 90kV
Leakage Technique Factors 5625 mAs/h @ 90kV/4mA
