9 Technical data
206718 rev 9
SOREDEX 97
2D modalities
The following charts represent technique factors that can
be used with the selected line voltage and continuous
radiation. One of the three technique factors is always
fixed.
Electrical connections
Nominal mains voltage 220-240V / 100-120V (Selectable)
Input power frequency 50 / 60 Hz
Nominal current 10A @ 230 VAC, 15A @ 110 VAC
Fuses 230 Vac:
Littelfuse 326 (slow blow) 10A
Cooper Bussman (time delay) MDA-10
110 Vac:
Littelfuse 326 (slow blow) 15A
Cooper Bussman (time delay) MDA-15
Power consumption 2.3 kVA @ 230 VAC, 1.65 kVA @ 110 VAC
Maximum impedance of main 0,2
Table 1: 100 VAC
mA
16
14
12.5 xx
11 xxxxx
10 xxxxxxx
9 xxxxxxxxx
8 xxxxxxxxxx
7.1 xxxxxxxxxx
6.3 xxxxxxxxxx
5.6 xxxxxxxxxx
5 xxxxxxxxxx
4.5 xxxxxxxxxx
4 xxxxxxxxxx
3.6 xxxxxxxxxx
3.2 xxxxxxxxxx
57 60 63 66 70 73 77 81 85 90 kV
