9 Technical data
206718 rev 9
SOREDEX 99
3D modalities
The following charts represent technique factors that can
be used with the selected line voltage in 3D imaging mode.
3D modality uses pulsed x-rays with fixed 90 kV and
exposure time.
Table 4: Exposure settings for 3D SFOV imaging
FOV
3D
Program
DAP (mGycm2) & Available mA ranges
3.2
mA
3.6
mA
4
mA
4.5
mA
5
mA
5.6
mA
6.3
mA
7.1
mA
8
mA
9
mA
10
mA
11
mA
12.5
mA
14
mA
61x41
mm
Minidose3033374246525865
Std Res 116 131 148 166 184 203 231
High Res 192 216 240 269 302 341 384 432 480 528 600
Endo 192 216 240 269 302 341 384 432 480 528 600
61x78
mm
(optional)
Minidose6169778696
Std Res 241 272 306 345 383 421 479
High Res 397 447 497 556 626 705 795 894 993
Positioning lights
Panoramic, TMJ & Maxillary Sinus
Programs
Cephalostat FH light
3D imaging programs
laser light
(CLASS 1 LASER PRODUCT)
max output 100µW
Warning symbols are placed next to the laser lights and
the label describing the laser light classification is placed
inside the carriage side cabinet. USA / Canada models
have different types of laser light stickers according to
local requirements.
Caution - use of controls or adjustments or performance
of procedures other than those specified herein may
result in hazardous radiation exposure.
IEC 60825-1:1993+A1:1997+A2:2001
X-ray generator
Nominal power 1750 W nominal at 90 kV, 12.5 mA
Tube voltage 57 - 90 kV (+/- 5 kV)
Tube current 3,2 - 16 mA (+/- 1 mA)
Supply frequency 75 - 150 kHz
Spine compensation kV / mA compensated
Spine compensation
mode
Pre-programmed
