9 Technical data
104 SOREDEX
206718 rev 9
Installation Standard wall mount with ±45° angled joint.
Optional base for free standing unit (unit height is
increased 25 mm).
Height x Width x Depth (inches/mm) 2414 x 965 x 1126mm (standard column)
94.9 x 38 x 44.3 inches -Max.
Weight 200 kg / 441 lbs. (Panoramic)
Unit physical measures:
CRANEX 3D ceph physical measures:
source-image distance (SID) 1745 mm / 68.7 inches
source-object distance (SOD) 1520 mm / 60 inches
Installation Standard wall mount with 45° angled joint. Optional base
for free standing unit (unit height is increased 25 mm)
Height x Width x Depth (inches/mm) 2414 x 1872 x 1126 mm
94.9 x 73.7 x 44.3 inches
Weight 250 kg / 551 lbs. (Cephalometric)
Ambient temperatures:
Transportation and Storage
-10°…+50°C
Operation Temperature +10°...+35°C, RH max. 85%, 700 - 1060 mbar
Ceph ready option (Ordered separately)
Options Description
Ceph Upgrade to CRANEX 3D pan Upgrade CRANEX 3D panoramic with Cephalometric
imaging.
Field upgrades for model CRANEX 3D
Upgrade Description
Cephalostat Upgrade Add ceph imaging to CRANEX 3D pan
Left / right Change handedness to pan ceph
3D Upgrade Add 3D imaging:
- Panoramic unit to 3D unit
- Panoramic unit to 3D MFOV unit*
- 3D unit to 3D MFOV unit*
*availability based on unit serial number, contact your
local distributor for more information.
