9 Technical data
206718 rev 9
SOREDEX 103
Cephalometric image receptor
Sensor unit interchangeable Ceph sensor
Technology/Sensor type CMOS
Image pixel size and depth 100 x 100 m and 14 bits
Active area height 223,2 mm / 2232 pixels
Image field width in lateral view 10.2 inches / 260 mm, maximum
6.7 inches / 170 mm, minimum
Image field width in PA view 7.9 inches / 200 mm
Resolution 4 LP/mm (cephalometric)
max height
223 mm
3D image receptor
Sensor unit 3D sensor
Technology/Sensor type CMOS Flat panel
Image pixel size and depth 200 m and 13 bits
Active sensor surface
(H x W)
100 x 68 mm
max height
129 mm
Unit physical measures:
source-image distance (SID) 500 mm (Panoramic)
570 mm (3D)
