9 Technical data
102 SOREDEX
206718 rev 9
Cephalostat patient positioning
Operation Arm mounts on left or right side of the unit Interlocked
pan/ceph sensor
Motorised carriage buttons at cephalostat head
assembly.
Positioning aids Ear holders, Nasion support with vertical mm scale,
Frankfort horizontal plane laser light, Contact plate
(Carpus program).
3D imaging patient positioning
Operation Left or right side of unit
Motorised carriage movement
Positioning aids Chin rest, chin support, chin cup
3-point headrest, hinged
mirror,
3 positioning laser lights
Cephalostat scanning
Scanning method Horizontal scan, synchronized sensor and secondary slot
motion
Scanning time 10 - 20 s.
Panoramic image receptor
Sensor unit Pan sensor or interchangeable Ceph sensor
Technology/Sensor type CMOS
Image pixel size and depth 100 x 100 m and 14 bits
Active area height 5.8 inches / 148 mm / 1480 pixels
Resolution 5 LP/mm (panoramic)
