3.1.6. Roller brake testers PFB060 series:
The roller brake tester PFB060 series consists of:
 roller brake tester PFB060 0000 without weighing equipment;
 roller brake tester PFB060 1000 with self-braking motors and without weighing equipment;
 roller brake tester PFB060 2000 with two sensors weighing equipment;
 roller brake tester PFB060 3000 with self-braking motors and two sensors weighing
equipment.
TECHNICAL SPECIFICATIONS PFB060
Roller dimensions
1000 -  205
Roller internal wire distance
800 mm
Roller external wire distance
2800 mm
Max. transit weight per axle
5000 daN
Motors
M112 5,5kW
Empty roller tip speed
2,5 km/h
Grip coefficient
>0,7
Precision measuring chain (2
sensor)
≤ ±3%
Weight
485 kg
WEIGHING FRAME TECHNICAL SPECIFICATIONS
Max. transit weight per axle
5.000 daN
Max. test weight per axle
4.000 daN
Precision measuring chain
≤ ±3%
Weight
30kg
Figure 6
