2.2. Indication of outstanding risks
The machine was designed and manufactured in compliance with applicable regulations. The risks
connected to the use of the machine have been eliminated as far as possible. Other outstanding
risks are described in this manual; the machine also features self-adhesive pictograms (chap 0
and 0 on page 15 and 16) indicating hazard areas. In the event pictograms become illegible, please
order them from a dealer or directly from SPACE S.R.L. and replace them. Please refer to Spare
Parts manuals.
2.3. Emergency devices
In case of an emergency, operate the special device on the rear of the cab as shown at Figure 7
and Figure 6 page 15 and 16 at ref. 8.
2.4. Safety devices
- Safety button: stops and prevents roller start (Button on the front of the cab shown at Figure
7 and Figure 6 on page 15 and 16 at ref. 3).
- Vehicle sensor rollers: these enable the start of the rollers only when they are both pressed.
- Slip/speed control sensor rollers: these stop roller rotation when an anomalous wheel speed
is detected of the vehicle being tested.
- Stop/F1 key: on the functional keyboard and remote control. For stopping roller rotation and
the test under way.
- Cab access doors: these prevent access to energized parts. These must only be opened by
professional and authorized personnel (Figure 7 and Figure 6 at ref. 9).
2.5. Emergency situations
ATTENTION!: In the event of emergency situations, the special device behind the console will
have to be operated (see Figure 7 and Figure 6 on page 15 and 16, at ref. 8), and
consequently, the console should be installed so the emergency device is easily
accessible. The user is responsible for inspecting and maintaining access to the
emergency device free of obstacles or impediments and for periodically checking
its efficiency.
ATTENTION!: Unauthorized persons must not be allowed to enter the test area. Only one
operator must work inside the test area and must not exit from the vehicle near
the roller tester. In the event of the operator, for any reason, not being able to
exit from the vehicle, he should ask for the assistance of a second operator who
may access the test area only after operating the emergency device.
ATTENTION!: The equipment also features a safety device on the front (Figure 7 and Figure 6
on page 15 and 16, at ref. 3); this prevents the rollers starting. This must be
disengaged, by turning clockwise, only after checking that no risk situations
exist. The disconnecting operation must be only executed after to have verified
that the conditions of emergency inside of the test area are respected. The rollers
are normally prevented from being started if the vehicle axle is not on the roller
assembly. Press the STOP key on the remote control or the red key on the
keyboard to stop the rollers; this is necessary if the vehicle brakes are not
working properly and do not allow automatic roller stoppage.
