User Manual
SPACE s.r.l.
Soc.a socio unico
PFB035 SERIES PFB040 SERIES
PFB045 SERIES PFB060 SERIES
SPRT102/4 SERIES SPRT102/5 SERIES
SPRT102/6 SERIES SPRT102/7 SERIES
Code M0247 - Ver.1.4
(09/2016)
SPACE s.r.l. 10090 TRANA (TO) Via Sangano, 48
Page 17/68
Tel. (+39) 011/ 934 40 300 Fax (+39) 011/ 933 88 64
e-mail: info@spacetest.it - www.spacetest.com
3.4. Console PFC750/WALL
Space saver control unit wall mounted.
It is available with PC, keyboard, 19 SVGA monitor and printer included or not.
Figure 9
IMPORTANT!: The door leading to the switchboard, the CPU board and power board can only be
opened by authorized personnel; these compartments contain high-voltage
components which can prove hazardous to unskilled operators.
TECHNICAL DETAILS
Power supply
400V 3ph + neutral
Precision
±0,5%
Weight
40 kg
