12. TROUBLESHOOTING
The following are a list of possible problems that could affect the TEST LANE. SPACE S.R.L. cannot
accept any liability for injury to persons and animals or damage to things resulting from machine
maintenance performed by unauthorized personnel or use of non-original spare parts.
Before doing any jobs on the machine, disconnect the power supply line at the main switchboard.
In case of any doubts, always immediately contact the SPACE S.R.L. after-sales service which
will be pleased to provide information suitable for performing operations in total safety.
The items marked by this symbol require the services of the after-sales department.
Do not perform operations on the machine
.
PROBLEM
CAUSE
REMEDY
NO OPERATION
- Power break
- Protection fuses interrupted
 Check mains voltage
 Check protection fuses
The monitor dos not work
- Power supply interrupted
- No video signal
 Check power cable connection
 Check video signal cable connection
between PC and monitor
PC fails to switch on
- Power supply interrupted
 Check ON/OFF switch
 Check power cable connection
Printer dos not work
(see also printer operation manual)
- Power supply interrupted
- No signal
 Check ON/OFF switch
 Check power cable connection
 Check signal cable connection between
printer and PC
PC keyboard
- No signal
 Check cable connection with PC
Remote control
- Obstacles between transmitter and
receiver
- Battery low (red LED does not come on)
- No signal
 Make sure there are no obstacles between
the transmitter and the receiver
 Replace the battery
 Check cable connection between receiver
and motherboard
Brake tester motors fail to start
- Protection fuses interrupted
- STOP button pressed
 Check protection fuses
 Disengage STOP button
Adherence test motors fail to start
- Protection fuses interrupted
- STOP button pressed
 Check protection fuses
 Disengage STOP button
Brake tester motor start signal failure
- CAR-ON vehicle sensor faulty
 Replace CAR-ON sensor
During TEST LANE operation, due to wrong operations by the operator or faulty devices, an error
code could appear on the screen.
Press the STOP/F1 key to return to previous program stage; if the error continues and is
systematic even when regular procedure is followed, contact the SPACE S.R.L. technical dept.
ERROR CODE
CAUSE
1 – During starting stage, LH CAR-ON is Off
LH CAR-ON has become inactive during starting stage
2 – During starting stage, RH CAR-ON is Off
RH CAR-ON has become inactive during starting stage
4 – Starting stage blocked through STOP key
STOP pressed during starting stage
5 – LH roller speed too low during starting stage
LH TACHO has detected a speed which is too low during starting stage
6 – RH roller speed too low during starting stage
RH TACHO has detected a speed which is too low during starting stage
7 – LH roller speed too high during starting stage
LH TACHO has detected a speed which is too high during starting stage
8 – RH TACHO speed too high during starting stage
RH TACHO has detected a speed which is too high during starting stage
9 – LHBP> max. full scale threshold during starting
stage
LH braking power > full scale threshold during starting stage
10 – RHBP > max. full scale threshold during starting
stage
RH braking power > full scale threshold during starting stage
11 – LHBP > max. rolling threshold
LH braking power > rolling threshold during starting stage
12 – RHBP > max. rolling threshold
RH braking power > rolling threshold during starting stage
13 – LHBP > max. full scale threshold during braking
stage
LH braking power > full scale threshold during braking stage
14 – RHBP >max. full scale threshold during braking
stage
RH braking power > full scale threshold during braking stage
15 – Braking not valid because it does not exceed min.
time
Braking stage shorter than set min. time. Braking threshold not exceeded
(rolling value + 50%)
17 – Oval stage not ended
- Sono stati bloccati i rulli durante la fase di ovalizzazione
39 – Trouble during adherence test, non-reliable data
- La prove di aderenza non ha rilevato minimi oppure ha rilevato minimi
inattendibili
