ACTIVE BOXES
Many of the iX20 menus include Active Boxes. These boxes represent switch positions when the
value or condition being shown will be active or inactive.
The active box appears grey by default, indicating the curve or condition is active at this switch
position. The switch position directly corresponds to the curve or condition. At switch position 0,
curve 0 is active. At switch position 1, curve 1 is active and so on.
Active Boxes
