REVERSE
Use the Reverse menu to reverse the travel direction of any channel. For example, if the elevator
moves up and it should move down, reverse the elevator channel travel direction.
To reverse a channel travel direction:
1. Select Reverse in the Servo Setup menu ribbon.
2. Touch the button next to the channel you wish to reverse.
If the throttle channel is reversed, a conrmation screen appears. Select YES to reverse the
channel. A second screen appears, reminding to re-bind the transmitter to the receiver, at low
throttle, to re-set the throttle failsafe.
CAUTION: Always rebind the transmitter and receiver after reversing the throttle channel.
Failure to do so will result in the throttle moving to full throttle if failsafe activates.
Always perform a control test after making adjustments to conrm the model responds properly.
