Appendix A: Multiple Chassis Local Connect
Setting Up and Powering Up Multiple Chassis
96 | SmartBits 600x/6000x Installation Guide
Power Down and Disconnect the Chassis
For powering down and disconnecting the chassis, we will use the example shown in
Figure A-5 on page 95.
To power down and disconnect the chassis:
1 Power down the expansion chassis in the reverse order of the powering up sequence,
starting with the last dependent controller chassis (#10) that has an RJ-45 Expansion
In connection only, and no Expansion Out connection.
2 Power down the dependent controller chassis #8 and #5.
3 Power down the master controller chassis #4.
4 You may power down the slave units (#1, #2, #3, #6, #7, and #9) any time after the
master controller chassis that they are connected to has been powered down.
