SmartBits 600x/6000x Installation Guide | 69
Chapter 3
LED Indicators
Light-Emitting Diodes (LEDs) confirm the status of your installed SmartBits chassis,
modules, and network link.
For module specifications, refer to the particular module type in the SmartBits System
Reference manual and in the SmartWindow online help.
In this chapter . . .
This chapter contains the following topics:
• SmartBits 600x/6000x Chassis Front Panel LEDs . . . . 70
• Over-temperature Sequence Condition (SmartBits 6000C) . . . . 72
• SmartBits 600x/6000x Chassis Back Panel LEDs . . . . 73
• ATM TeraMetrics Module LEDs . . . . 74
• Ethernet Module LEDs . . . . 75
• LEDs on Ethernet SmartMetrics/TeraMetrics XD Modules . . . . 77
• Packet Over SONET (POS) Module LEDs . . . . 78
• Fibre Channel Module LEDs . . . . 79
• 10 Gigabit Ethernet Module LEDs . . . . 80
