Chapter 1: About SmartBits Chassis
SmartBits 6000C Chassis
14 | SmartBits 600x/6000x Installation Guide
SmartBits 6000C Chassis
The SmartBits 6000C chassis (Figure 1-5) is an ultra high-density network performance
analysis test system with enhanced cooling and power capabilities that support full loads
(up to 96 ports) of Spirent’s powerful SmartBits modules. The SmartBits 6000C chassis
performs the same functions, uses the same modules, and uses the same applications as the
SmartBits 600x/6000B chassis.
Figure 1-5. SmartBits 6000C Chassis
Table 1-2 on page 14 describes the maximum number of ports and modules that can be
used per chassis.
Table 1-2. Maximum Number of Ports and Modules per SmartBits 6000B/6000C Chassis
SmartBits 6000B
1
,
2
SmartBits 6000C
3
Type of Module
Maximum
Ports per
Module
Maximum
Modules
per
Chassis
Maximum
Total
Ports per
Chassis
Maximum
Ports per
Module
Maximum
Modules
per
Chassis
Maximum
Total
Ports per
Chassis
10/100 Mbps Ethernet
non-XD modules only 8 12 96 8 12 96
Gigabit Ethernet
1000 Mbps Ethernet
(non-XD modules only)
4124841248
10/100/1000 Mbps and Gigabit Ethernet Fiber SmartMetrics/TeraMetrics XD
LAN-3306A, LAN-3324A,
LAN-3325A
4
6
4
2441248
LAN-3320A, LAN-3321A 2
12
5
2421224
LAN-3327A 1 12 12 1 12 12
