SmartBits 600x/6000x Installation Guide | 27
Chapter 2
Installation and Setup
In this chapter . . .
This chapter contains the following topics:
• Summary of Installation Procedures . . . . 28
• Procedure 1: Check the System Requirements . . . . 29
• Procedure 2: Check the Chassis and Package . . . . 30
• Procedure 3: Install SmartBits Applications . . . . 32
• Procedure 4: Connect SmartBits to PC, Power, and LAN . . . . 34
• Procedure 5: Install the Ferrite Block . . . . 36
• Procedure 6: Connect the SmartBits Power Cord . . . . 38
• Procedure 7: Start SmartWindow . . . . 38
• Procedure 8: Set the IP Address . . . . 41
• Procedure 9: Confirm the Ethernet Link . . . . 51
• Procedure 10: Update Firmware Version (optional) . . . . 56
• Procedure 11: Connect SmartBits to an Application . . . . 65
• Procedure 12: Connect to the DUT and Check Cabling . . . . 67
