About This Guide
Conventions
4 | SmartBits 600x/6000x Installation Guide
chassis. Specific versions of the SmartBits 600x/6000x chassis are mentioned only
when required for clarification.
• The terms DUT and device under test, as well as SUT and system under test, are used
interchangeably in this guide. DUT/SUT is also used to indicate either.
• The terms packet and frame are used interchangeably.
• The term SmartCard refers to a printed circuit board used in a SmartBits 200/2000
chassis. The term module generally refers to a printed circuit board used in a
SmartBits 600x/6000x chassis. The term card is often used in SmartBits software
applications and in this guide to refer to either type of circuit board.
Notes, cautions, warnings, and important information are indicated as follows:
Note: Calls attention to additional information or explanation.
!
Caution: Calls attention to procedures or practices that should be followed to avoid dam-
age to hardware, or corruption and possible loss of software files and/or data.
Warning: Calls attention to operating procedures or practices that should be followed to
avoid bodily injury or damage to equipment.
Important: Calls attention to important information or characteristics that might be over-
looked.
Tip: Calls attention to helpful information about a product's operation or setup that eases
its use.
Indicates the beginning of a procedure.
